EDM Display



An EDM (Electrical Discharge Machining) display typically shows critical information about the machining process. Here are some common elements:

Main Display

1. Machining coordinates (X, Y, Z)

2. Workpiece dimensions

3. Tool offset values

4. Machining speed and feedrate

5. Spark gap voltage/current


Status Indicators

1. Machine status (idle, machining, alarm)

2. Axis movement (jog, feed, rapid)

3. Spindle status (on/off, speed)

4. Coolant status (on/off)

Alarm and Error Messages

1. Overtravel or axis limit alarms

2. Short circuit or spark-out detection

3. Tool breakage detection

4. System errors or warnings

Graphical Displays

1. Machining path visualization

2. Tool path simulation

3. Workpiece geometry display
